Up to 100 pallets/hour
Keeps pace with demanding automatic lines through fast, repeatable cycles.
High-speed automatic wrapping
Automatic ring wrapper for high-output production lines
Applies stretch film quickly, evenly and accurately to stabilise palletised loads with low film consumption and maximum uptime.
Request a quote100
pallets/hour
300%
pre-stretch
2,000
kg load
2,400
mm height
Speed and reliability
Consistent wrapping with an optimised mechanical system
The automatic ring wrapper is designed for high-output lines that demand speed, precision and maximum reliability. Its operation is based on an optimized mechanical principle that simplifies the system while ensuring uniform film application and precise adaptation to each load size.
The mechanical synchronization of the pre-stretch system allows wrapping with the minimum amount of film without compromising pallet stability, while its design eliminates sliding contacts, transmission belts, buffer batteries and onboard energy consumption. The result is low-maintenance equipment with high operational safety and an excellent cost-benefit ratio, with fewer stops, lower energy consumption and better wrapping quality.
How the cycle works
- 1
Pallet infeed
The conveyor positions the load in the wrapping area and starts the automatic cycle.
- 2
Film clamping
The system secures the film end and prepares application at the programmed tension.
- 3
Ring rotation
The ring rotates around the pallet and distributes film evenly over the full load height.
- 4
Cut and outfeed
The film is automatically cut and secured before the pallet moves to the next stage.
Benefits
High output with lower consumption and maintenance
Synchronised pre-stretch
Reduces film consumption without compromising load stability.
Low maintenance
The simplified design eliminates sliding contacts, belts and onboard batteries.
Complete integration
Combines with conveyors, top-sheet applicators and other end-of-line equipment.
Technical features
Designed for continuous industrial wrapping
- • Maximum load height: 2,400 mm / Custom
- • Output: Up to 100 pallets/hour
- • Maximum load: 2,000 kg / Custom
- • Maximum pallet diagonal: 1,700 mm
- • Film thickness: 12 to 30 microns
- • Maximum reel width: 500 mm
- • Pre-stretch: Up to 300%
- • Optional top sheet applicator device
- • Industrial construction for intensive use
Applications
Automatic wrapping for demanding industries
- High-output automatic lines.
- Regular or variable palletised loads.
- Products requiring dust and moisture protection.
- Ceramics, food, beverages, chemicals and construction.
- End-of-line systems with automatic conveying.
- Projects prioritising film savings and uptime.
Frequently asked questions about ring wrappers
What output is it designed for?
For high-speed automatic lines requiring consistent wrapping of up to 100 pallets per hour.
How does it reduce film consumption?
Mechanical pre-stretch synchronisation controls the amount of film without losing holding force.
Can it apply a top sheet?
Yes. An optional applicator improves protection on top of the load.
For all types of industries
We design wrapping around your automatic line
We analyse format, throughput, stability and protection to configure the ring, pre-stretch and auxiliary equipment.
