Four-side compaction
Head travel and guide movement help compact the pack evenly.
Horizontal strapping
Automatic horizontal strapping machine for compact pallet loads
Horizontal strapping system for palletized loads that require stability, side compaction and uniform retention during transport and storage.
The machine combines head travel, moving strap guide and precise tension control to handle different pallet formats in demanding automatic lines.
60
pallets/hour
700 kg
adjustable tension
MS300
strapping head
8-19 mm
PP/PET strap
Strapping process
Stable horizontal strapping for palletized loads
The horizontal strapper applies one or more straps around the palletized load, compacting it laterally and reinforcing product stability. It is especially useful when perimeter retention, controlled pressure and repeatability are required.
How the machine works
- 1The pallet enters the strapping position.
- 2The head and strap guide are positioned according to strapping height.
- 3The strap is launched around the load contour.
- 4The strap is tensioned, welded and cut automatically.
- 5The compact pallet exits ready for shipping or downstream processes.
Horizontal strapping advantages
Main advantages of the horizontal strapper
Controlled high tension
Strap force can be adjusted to the product and required retention.
Automatic integration
It integrates with conveyors, palletizing, hooding or wrapping systems.
MS300 head
Industrial high-performance head for repeatable intensive cycles.
Project adaptation
Configuration can be adapted to pallet size, strap heights and throughput.
Technical features
Technical features
- • Output: up to 60 pallets/hour
- • Strap type: Polypropylene (PP) and Polyester (PET)
- • Compatible strap width: 8-19 mm
- • Strap tension: adjustable up to 700 kg
- • Maximum load: 2,000 kg / Custom
- • Maximum load dimensions: 1,200 x 1,200 mm / Custom
- • Maximum load height: 2,600 mm
- • Strapping head: MS300
- • Motorized coil holder with speed control
Applications where it fits especially well
- • Palletized loads requiring side compaction.
- • Construction materials, ceramics, glass, wood and industrial formats.
- • Lines with automatic shipping and high repeatability.
- • Products requiring strapping at one or several heights.
- • Projects combined with hooding, wrapping or automatic transport.
- • End-of-line systems where pallet stability is critical.
FAQ
Frequently asked questions about horizontal strapping
When is a horizontal strapper recommended?
When the load requires side compaction and perimeter retention, especially with heavy pallets, irregular formats or products that must remain stable during transport.
Can the strapping height be adjusted?
Yes. The machine can be configured to apply straps at different heights according to the load format and stability requirements.
Can it be integrated with other end-of-line machines?
Yes. It can be integrated with conveyors, palletizers, hooders, wrappers, weighing, labeling and other automatic modules.
For all types of industries
Let's talk about your horizontal strapping project
We review your pallets, throughput, strap type, application heights and line integration to define the most suitable horizontal strapper.
